Overall Dimensions |
9780mm*2496mm*3990mm(L*W*H) |
||
|
Tare Weight |
13950kg |
Payload |
35000kg |
|
Front Overhang |
1500mm |
Rear Overhang |
2880mm |
|
Wheelbase |
4000mm+1400mm |
Track (F/R) |
2022mm/1830mm |
|
CHASSIS |
|||
|
Chassis Brand |
SINOTRUK HOWO |
||
|
Chassis Model |
ZZ1257N4048W, driving type 6x4 |
||
|
Cab |
HW76, left hand drive, air-conditioner, one sleeper |
||
|
Engine |
SINOTRUK WD615.47, 371hp(273KW), Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L |
||
|
Transmission |
HW19710, No. of speeds: 10 forward 2 reverse |
||
|
Steering |
German ZF8098, turning system pressure 18MPa |
||
|
Rear Axle |
HC16 tandem axle, rated load 2x13ton, ratio 5.73 |
||
|
Wheels and tires |
Rim 9.0-22.5; tire 12R22.5, 10 units; Spare wheel carrier: with one spare wheel |
||
|
Brakes |
Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compressed air operating on rear wheels; Auxiliary brake: Engine exhaust brake |
||
