| Model | HC45Y | HC60Y | HC65Y |
| Operating Load (kg) | 700 | 800 | 950 |
| Max. Speed (km/h) | 12 | 12 | 12 |
| Hydraulic flow (L/min) | 62.5 | 75 | 75 |
| Tire Model | 10-16.5 | 12-16.5 | 12-16.5 |
| Rated Power (kW) | 37 | 45 | 55 |
| Fuel tank Volume (L) | 70 | 80 | 80 |
| Self Weight (kg) | 2700 | 2800 | 3000 |
| Bucket Volume (m³） | 0.4 | 0.5 | 0.5 |
Note: Our products are being updated constantly, all rights reserved by HAMAC.
Structure Data:
| Main data/Model | HC45Y | HC60Y | HC65Y |
| Overall operating height (mm) | 3980 | 4000 | 4000 |
| Height to bucket hinge pin (mm) | 3080 | 3100 | 3100 |
| height to top of cab (mm) | 2140 | 2160 | 2160 |
| Height to bottom of level bucket(mm) | 2913 | 2933 | 2933 |
| Overall length without bucket(mm) | 2640 | 2750 | 2750 |
| overall length with bucket(mm) | 3420 | 3490 | 3490 |
| Dumping angle at maximum height(° ) | 40 | 40 | 40 |
| Dumping height(mm) | 2380 | 2400 | 2400 |
| Dumping reach(mm) | 700 | 750 | 750 |
| Rollback o bucket on ground(° ) | 30 | 30 | 30 |
| Rollback of bucket at full height(° ) | 104 | 104 | 104 |
| Wheelbase(mm) | 991 | 1085 | 1085 |
| Ground clearance(mm) | 185 | 205 | 205 |
| Angle of departure(° ) | 20 | 20 | 20 |
| Front turning radius without bucket(mm) | 1168 | 1198 | 1204 |
| Front tuning radius(mm) | 1958 | 1958 | 2030 |
| Rear tuning radius(mm) | 1630 | 1728 | 1706 |
| Rear axle to bumper (mm) | 1108 | 1208 | 1082 |
| Tread width, centerline to centerline (mm) | 1450 | 1500 | 1500 |
| Width (mm) | 1720 | 1880 | 1880 |
| Bucket width (mm) | 1740 | 1880 | 1880 |
