| Model | SELF LOADING VERTICAL SHAFT CONCRETE MIXER HMC190 |
| Drum Capacity | 1.9 cubic meters. Concrete output 1.5m3/batch |
| Mixing | Shaft flat forced mixing |
| Loading | Grabbing bucket |
| Loading Speed | 5 buckets/min，150L/bucket |
| Production capacity | 4 batches one hour,6 cubic meters/hour |
| Walking Speed |
Low speed;0—20km/hour， High speed; 0—30km/hour |
| Discharging | Bottom discharge 1m, bucket discharge height 4m |
| Engine | ChangChai, HS400, Single-cylinder, water cooling,2200rpm/min, rated power; 40HP |
| Transmission | By mechanical 4X4 |
| Cab | Left Cab |
| Discharging outlet | Two directions, rear and side. |
| Brake | Oil brake, double independent circuit. Hub handbrake. |
| Steering | Front wheel hydraulic steering. |
| Tyre | 7.0-16 |
| Electrical | 24V |
| Weight | 4300kg |
| overall Dimensions | L：4.9M W：2M H：3M |
Note: Our products are being updated constantly, all rights reserved by HAMAC.
